waste tyre recycling machine pyrolysis plant
Basic Info
Model No.: ZL-10
Product Description
About Us
Shangqiu Sihai Machinery Equipment Co., Ltd. is a collection of research and development, production, sales and after-sales services, which has rich experience in the field of waste management over 20 years.
Our company covers an area of 37,000 square meters. Our company has a huge professional technical team, including 2 senior engineers, 16 senior technicians, 28 mid-class technicians, and 82 technicians.
Our main products are divided into two catalogries: pyrolysis plant and distillation machine, including tires
pyrolysis plant, tyre pyrolysis plant, waste rubber pyrolysis equipment, waste plastic recycling machine
and other waste management machines, and waste oil distillation equipment, waste engine/motor oil recycling machine, tire oil distillation plant, plastic oil refinery machine and crude oil distillation equipment.
Product Details
Model:LJ-10 Raw material:Waste tire, waste plastic, waste rubber
Structure:Horizontal 24hours processing capacity:10-12tons raw materials
24hours oil output:4-6tons fuel oil Work pressure:Atmospheric
Host speed:0.4r\min Power:15.5KW
Cooling:Water cooling Lose water(T\H):8
Transport:External gear drive Heating method:Directly
Installation:Foundation Noise dB(A):≤85
Reactor size length*wideth:2600x6600 Working form:batch
Weight of Reactor(T):30 Manufacuring time:20days
This kind of machine does not have to get rid of silt, moisture content, iron wire impurity and so on from the scrap plastic, directly loads in the rotary system high temperature atmospheric pressure split processor, catalyses, heats up, distils oil steam, the oil gas through the condenser, the liquefied part condense into the oil mixture, and the unliquefied part holds through the fuel gas system into the processor bottom to burn.After the mixture oil condense, put into fractionation processor to heat though catalytic reforming process, and get the oil steam. Then the oil steam through the condenser to be basic fuel, and add various additives to become qualified fuel.
Main Technological Characteristics
1. The heating method of the new equipment is indirect heating method, and the advantages of
this method are as follows:
. When some problems occur in the system, closing the induced draught fan can cut the heating
source in sudden to ensure the systems safety.
. The heat exchange distance is more than that of the old equipment by 5-7 times, thus having
a higher thermal efficiency.
. Extend greatly the service life of main equipment, and the service life of the new equipment is
longer than that of the old one by 2-3 times.
2. Equipments Shape: beautiful and decent, and economic and practical.
3. Catalyzing heat split technology and chemical extracting technology for product
4. The equipped environmental protection fittings are more perfect, such as waste gas burner,
and flue dust chamber.
5. The equipment has reasonable design and advanced manufacturing technologies and a high
automation degree and complete safety facilities.
After -sales Service 1.Quality warranty period: One year warranty for the chamber of the distillation machines,and lifetime maintenance for complete set of machines. pay the double air tickets, accommodation and food. 2.According to the requirement of the buyer, our company sends engineers for installation in buyer's site including the training of skills of buyer's workers on operation, maintenance, etc. 3. Supply layout according to buyer's workshop and land, civil works information, operation manuals, etc. to the buyer.
Product Categories : Waste Tire Pyrolysis Plant
